Peripheral Pump

Model:PN59/PN60/PN65/PN70

As the professional manufacturer, RISEFULL® would like to provide you Peripheral Pump. And RISEFULL® will offer you the best after-sale service and timely delivery. One of the key features of the Peripheral Pump is its ability to conserve energy. Its efficient motor is specifically designed to consume minimal amounts of energy, reducing your energy bills without sacrificing performance.

Send Inquiry

Product Description

You can rest assured to buy Peripheral Pump from RISEFULL® factory and we will offer you the best after-sale service and timely delivery. One of the key features of the Peripheral Pump is its ability to conserve energy. Its efficient motor is specifically designed to consume minimal amounts of energy, reducing your energy bills without sacrificing performance. This makes it an ideal choice for businesses, farms, and homeowners looking for an energy-efficient alternative.

Another key advantage of the Peripheral Pump is its ease of use. The pump comes with easy-to-follow instructions for quick and effortless installation. With just a few basic tools, you can have your pump up and running in no time. Additionally, the pump's design ensures low maintenance requirements, reducing the need for costly repairs and frequent replacement.

The following is an introduction of PN Series .It is the pipeline booster, premium vortex pump which is used to solve the pipeline insufficient pressure problem of the apartments and single buildings .Hope to help you better understand Risefull domestic water pump . Welcome new and old customers to continue to cooperate with us to create a better future together

Product Specification:

Product Name:	Pipeline Booster
Power	0.45HP/0.5HP/0.75/HP/1HP
Max Flow	36L/min 42L/min 55L/min 68L/min
Max Head	32M 36M 42M 48M
Inlet/outlet	1”X1”
Pump Body	Cast Iron with Elector-coating
Bracket	Aluminium Bracket with PPO insert
Shaft	S.S Shaft
Impeller	Brass Impeller
Motor	Cooper wire or Aluminium
Color	Powder Color Coating
MOQ:	100pcs
Sample Time:	Within 7 days
Production Time:	35-40 days after order confirmation
Certificate	CE

Product Details

Peripheral Pump

Working Condition

● Clean liquid without suspend solids ,non aggressive

● Continuous Service :S1

● Maximum Pressure:10 Bar

● Liquid Temperature:3℃~90℃

● Ambient Temperature:<40℃

● Insulation:B

● Protection:IP44

● Solid Diameter:≤2mm

Performance Data

Item	Power		Max Flow	Max Head	Rated Point	Flow Sug.	Floor Sug
Item	kW	HP	Max Flow	Max Head	Rated Point	Flow Sug.	Floor Sug
PN59	0.33	0.45	36L/min	32M	16M@20L	x1.5	3 Floor
PN60	0.37	1/2	42L/min	36M	16M@25L	x1.5	4 Floor
PN65	0.55	3/4	55L/min	42M	20M@32L	X2	5 Floor
PN70	0.75	1	68L/min	48M	24M@38L	X2	6 Floor

Peripheral Pump

List of Main Component ●Standard Configuration 〇 Optional Configuration
NO.	Component	Specification/Construction Characteristics
1	PUMP BODY	Cast Iron HT200, Electro-coating Finished (Salt Spray Resistant Test For 300+ Hours)
2	IMPELLER	●Brass（H58%+）〇 PPO（High Temperature Resistant for 150℃）〇 Stainless Steel（SUS304 Stamping & Welding）
3	Mechanical Seal	●301 Type（Karbate Impervious Graphite+Ceramic）〇CN Type（Karbate Impervious Graphite+Ceramic, Special Construction Stand For Start-stop Frequently）〇 14DIN Type（Furan Impregnation Graphite+SIC，Use Life 25,000+ Hours）
4	Bracket Plate	●PPO（High Temperature Resistant For 150℃）〇 Precision Casting SUS304 〇 Brass(H57%+)
5	Bracket	Aluminum ADC12
6	Ball Bearings	●Standard Type 〇 C&U 〇 TPI(Taiwan)
7	Motor Shaft	●SUS410(2CR13) 〇 Welding Shaft: Stainless Steel 304 (Pump Side)+Carbon Steel (Motor Side)
8	Terminal Box	Plastic ABS
9	Terminal Board	Flame Retarding PBT
10	Capacitor	●CBB60 Plastic Shell Capacitor 〇 CBB65 Explosion-proof Capacitor 〇 450VL@220-240V Motor 〇 300VL@110-127VMotor
11	Motor Housing	Aluminum ADC12
12	Fan	●Plastic PP 〇 Nylon PA6
13	Fan Cover	Plastic PP
14	Plug Cord	● 3 Core Testing Cable 〇 Customized Cable Plug
15	Motor	●Standard Copper Wire 〇 High Efficiency Motor 〇 Economical Motor 〇 3-Phase Motor 〇 Customized 60 HZ Motor
