Premium Self-Priming Peripheral Pump

Model:PS59/PS60/PS65/PS70

RISEFULL® is one of China manufacturer & supplier who mainly produces Premium Self-Priming Peripheral Pump with many years of experience. Hope to build business relationship with you.

Send Inquiry

Product Description

Efficiency is key when it comes to pumping systems, and the Premium Self-Priming Peripheral Pump delivers just that. Thanks to its self-priming feature, you won't have to worry about manually priming the pump or dealing with performance issues caused by air bubbles. This means you can rest easy knowing that your pumping system is not only efficient and durable but also safe.For added convenience, the Premium Self-Priming Peripheral Pump also features a range of safety features. Its built-in thermal overload protection prevents overheating, while its automatic shut-off feature kicks in if the pump runs dry.

This pump is also designed with durability in mind. Its high-quality construction ensures that it can handle even the toughest jobs and will last you for years to come. What's more, its compact size and lightweight design make it easy to transport and install wherever you need it.

The following is an introduction of PS Series .It is the self-priming peripheral pump which is used in the cooling circulation system .Hope to help you better understand Risefull Indutrial water pump . Welcome new and old customers to continue to cooperate with us to create a better future together

Product Specification:

Product Name:	Self-priming Peripheral Pump
Power	0.4HP/0.45HP/0.5HP/0.75/HP/1HP
Max Flow	30L/min 36L/min 42L/min 55L/min 68L/min
Max Head	28M 32M 36M 42M 48M
Inlet/outlet	1”X1”
Pump Body	Cast Iron with Elector-coating
Bracket	Aluminium Bracket with PPO insert
Shaft	S.S Shaft
Impeller	Brass Impeller
Motor	Copper wire or Aluminium
Color	Powder Color Coating
MOQ:	100pcs
Sample Time:	Within 7 days
Production Time:	35-40 days after order confirmation
Certificate	CE

Product Details

Premium Self-Priming Peripheral Pump

Working Condition

● Clean liquid without suspend solids ,non aggressive

● Continuous Service :S1

● Maximum Pressure:10 Bar

● Liquid Temperature:3℃~90℃

● Ambient Temperature:<40℃

● Insulation:B

● Protection:IP44

● Solid Diameter:≤2mm

Performance Data

Premium Self-Priming Peripheral Pump

Model		Power		Q	m³/h	0	0.3	0.6	0.9	1.2	1.5	1.8	2.1	2.4	2.7	3.0	3.3	3.6	3.9
Single-phase	Three-phase	kW	HP	Q	L/min	0	5	10	15	20	25	30	35	40	45	50	55	60	65
PS55	PS55T	0.3	0.4	H	M	28	24	20	*16	*12	*8	3.5
PS59	PS59T	0.33	0.45			32	28	24.5	*20.5	*16	*12	*18.5	4
PS60	PS60T	0.37	0.5			36	32	28	24	*19.5	*15	*11	7	3
PS65	PS65T	0.55	0.75			42	38	34	30	26	*22	*18	*14	*10	6.5	3
PS70	PS70T	0.75	1			48	44	40	36	32	28.5	*25	*21.5	*18	*15	*12	9	6

*High Efficiency Eta Of Pump

Premium Self-Priming Peripheral Pump

List of Main Component ●Standard Configuration 〇 Optional Configuration
NO.	Component	Specification/Construction Characteristics
1	PUMP BODY	Cast Iron HT200, Electro-coating Finished (Salt Spray Resistant Test For 300+ Hours)
2	Inlet Flange	Aluminium ADC12,Rubber Check-valve Inside(EPDM)
3	IMPELLER	●Brass（H58%+）〇 PPO（High Temperature Resistant for 150℃）〇 Stainless Steel（SUS304 Stamping & Welding）
4	Mechanical Seal	●301 Type（Karbate Impervious Graphite+Ceramic）〇CN Type（Karbate Impervious Graphite+Ceramic, Special Construction Stand For Start-stop Frequently）〇 14DIN Type（Furan Impregnation Graphite+SIC，Use Life 25,000+ Hours）
5	Bracket Plate	●PPO（High Temperature Resistant For 150℃）〇 Precision Casting SUS304 〇 Brass(H57%+)
6	Bracket	Aluminum ADC12
7	Ball Bearings	●Standard Type 〇 C&U 〇 TPI(Taiwan)
8	Motor Shaft	●SUS410(2CR13) 〇 Welding Shaft: Stainless Steel 304 (Pump Side)+Carbon Steel (Motor Side)
9	Terminal Box	Plastic ABS
10	Terminal Board	Flame Retarding PBT
11	Capacitor	●CBB60 Plastic Shell Capacitor 〇 CBB65 Explosion-proof Capacitor 〇 450VL@220-240V Motor 〇 300VL@110-127VMotor
12	Motor Housing	Aluminum ADC12
13	Fan	●Plastic PP 〇 Nylon PA6
14	Fan Cover	Plastic PP
15	Plug Cord	● 3 Core Testing Cable 〇 Customized Cable Plug
16	Motor	●Standard Copper Wire 〇 High Efficiency Motor 〇 Economical Motor 〇 3-Phase Motor 〇 Customized 60 HZ Motor

Installation Dimensions

Premium Self-Priming Peripheral Pump

Model	DN1	DN2	Main Intallation Dimension(mm)
Model	DN1	DN2	a	f	h	h1	i	l	m	n	n1	w	s
PS59	G1	G1	37	245	211	166	128	207	89	117	94	51	10
PS60	G1	G1	37	245	208	164	129	204	89	117	94	51	10
PS65	G1	G1	37	272	235	185	137	231	96	140	114	59	10
PS70	G1	G1	38	272	248	200	149	244	96	140	114	58	10

Working Current

Item	1~220V/50Hz	3~380V/50Hz
PS55	1.5A	0.5A
PS59	2.1A	0.7A
PS60	2.7A	0.8A
PS65	4A	1.5A
PS70	5.8A	2A

Packaging Information

Model	N.W.	PCS/CTN	G.W/CTN	MEAS （CM)	PCS/CTN	G.W/CTN	MEAS （CM)
PS55	5.30	1	5.85	25X18X23	4	24.40	37.5X26.2X49
PS59	5.80	1	6.10	25X18X23	4	25.50	37.5X26.2X49
PS60	6.00	1	6.40	25X18X23	4	26.70	37.5X26.2X49
PS65	9.30	1	9.80	28X25X29	2	20.70	51.5X29X30
PS70	11.30	1	11.80	28X25X29	2	24.70	51.5X29X30
